Product Introduction

The High Frequency Phase-Stable Low Loss Coaxial Cable Series, along with High Frequency Cable Auxiliaries and High Frequency Test Cable Auxiliaries, are widely used in the aerospace industry, electronic countermeasures systems (ECM), high-frequency anechoic system connections, and 5G mobile communications, among other applications.


Model

Model Code Frequency range Interface type Cable type Cable length PDF 详情
N-F-N-F(75Ω） DC-12GHz N-F-N-F N-F-N-F(75Ω) 500/500mm /
E18L-NFNM-01.00M DC-18GHz N-F/N-M E18L 1000mm /
E40-29M29M-01.00M DC-40GHz 2.92-M/2.92-M E40 1000mm /
SWA360-2.92/M-2.92/M DC-40GHz 2.92/M-2.92/M SWA360 500/500mm /
BNC-M-BNC-M-RF1.32-500mm DC-3GHz BNC-M/BNC-M RF1.32 500mm /
SMA-M-SMA-F-RG178-500mm DC-3GHz SMA-M/SMA-F RG178 500mm /
