JINPAT USB 2.0 slip rings ensure stable 480Mbps data transmission during rotation.
They support integration with a variety of signal types, including U3, E2, E3, SDI (SD1/SD2), HD video, and general power/control signals.
They are ideal for applications requiring compact size and multi-signal rotary connectivity.
Features:
Supports high-speed transmission rates up to 480Mbps.
Integrates U3, E2, E3, SD1, SD2, HD signals, and general electrical/data signals.
Multi-channel integrated design combines power, video, and control signals.
-
Compact structure, stable transmission, and strong anti-interference capabilities.
Applications:
Video Surveillance
Medical Equipment
Automation Systems
Customization & Services
Tailor your slip ring with specific signal types, channel counts, protection levels, or mounting styles. 3D CAD models and technical support are available upon request.
Can’t find a suitable model? Contact us for 24/7 technical support .
For detailed product specifications , refer to product datasheets or contact our sales team.
Optimized for global markets – Precision-engineered for reliability in mission-critical applications.
USB 2.0 Slip Rings |
|
Typical Model
|
USB 3.0 Channels
|
Circuits
|
Voltage
|
Size |
| Outer Diameter |
Length |
LPMS-01U2-0601-04S |
1 |
6 |
0~48V AV/DC
|
Φ7.6 |
19.1 |
| LPMS-02U2-0201-06S |
2 |
2 |
Φ7.98 |
22 |
| LPM-02U2-0402-04S |
2 |
4 |
0~110V AV/DC
|
Φ12.8 |
23.5 |
| LPM-04U2-0501-05S |
4 |
5 |
Φ16 |
37 |
| LPC-02U2-1002-16S |
2
|
10 |
0~220V AV/DC
|
Φ22 |
57.3 |
| LPC-08U2-1002-06S |
8 |
10
|
Φ25 |
85.7 |
